Indoor Badminton Hall Steel Construction

IMINININGWANE EYISISEKELO

Ibhrendi

EIHE

Le yindawo ka Origin

I-Qingdao, China

Umkhiqizo/Isevisi

Isakhiwo sensimbi nokwakhiwa okuhlobene

Imigomo Yentengo

FOB / EXW

Imigomo Yokukhokha

T/T

Ukupakisha

Kulungiswe ngohlaka lwensimbi

Ezokuthutha

Izimpahla zasolwandle

I-MOQ

200 m²

Isikhathi sokuthumela

Izinsuku ezingama-20-50

Isistimu Yesakhiwo Esiyinhloko

Izingxenye Ezibalulekile

I-I-I-Enclosure System

I-Planar Arch Truss System

I-Main Truss / Roof Truss

I-Metal Roof Panel

Misa i-Dome System

Ikholomu Yensimbi

I-Thermal Insulation Cotton

I-Portal Rigid Frame / Uhlaka Lwensimbi

I-trus yesibili

I-Inner Metal Panel

I-Modular Steel Truss System

I-Roof Purlin

Udonga olumunca umsindo

IHybrid Structural System

Ukugwedla Phakathi Kwamakholomu

Daylighting Strip

I-Wall Purlin

I-Ventilator yemvelo

Izinzuzo Eziyinhloko

Izimo Ezisebenzayo

Izimo Zokubukwayo zezinga lochwepheshe

Izinkundla Zemincintiswano Yomsebenzi

Ideal Clear Height

Izinkundla Zemincintiswano Yomsebenzi

I-Dimmable Professional Lighting

Amahholo e-Badminton Ezohwebo

Isivinini Sokwakha Esisheshayo Kakhulu

Izikole / Izindawo Zomphakathi

Umthamo omkhulu we-span

Izikhungo Zokuqina Zebhizinisi

Ukumuncwa Komsindo Nokuncishiswa Komsindo

Amahholo Ezemidlalo anemisebenzi eminingi

I-Architectural Expressiveness

Ukusebenza kahle kwezindleko

Ulwazi Oluyisisekelo

Ibanga Lezinto Eziyinhloko

Q235B/Q355B

I-span

21m-60m+

Uhlobo Lwesigaba

I-Welded H-beam / i-H-beam egoqelwe ngokushisayo / I-Truss Yepayipi Lensimbi

Ukumelana Nomlilo

Ibanga II

I-anti-corrosion

I-Hot-dip Galvanized / Composite Coating Structure

Impilo Yesevisi Yokuklama

Ngaphezu kweminyaka engama-50

I-I-I-Enclosure System

Udonga Lwangaphandle Luphelile

Ishidi Lensimbi Yombala We-Aluzinc Ehlanganisiwe

I-Insulation Layer

Uvolo Wengilazi

Udonga Lwangaphakathi Luphelile

Ishidi Lensimbi Yombala Omnyama / Omatte noma Iphaneli Emunca Umsindo

Uhlelo lwaphansi

Professional Sports Flooring

Indawo kanye nobude obucacile

Ubukhulu benkantolo eyodwa

13.4m × 6.1m

Ngaphandle komugqa oseceleni

≥1.5m

Indawo yebhafa ngaphandle komugqa wokugcina

≥2m

Sula ukuphakama

≥8m

Isikhala phakathi kwezinkantolo

≥2m

Imithwalo Yedizayini Yesakhiwo

I-Roof Dead Load

0.30 kN/m²

I-Roof Live Load

0.50 kN/m²

Umthwalo Womoya

0.50 kN/m²

I-Seismic Intensity

Ibanga lesi-8

Isisindo Sesistimu Yophahla

Cishe u-0.23 kN/m²
